be quiet! Pure Power 13 M 650W is ATX 3.1 compliant and PCIe 5.1 compatible, 10-year manufacturer's warranty

$135.00

Pure Power 13 M 650W – ATX 3.1 Power Supply with PCIe 5.1 Support

The Pure Power 13 M 650W is an ATX 3.1 compliant, PCIe 5.1 compatible power supply with semi-passive cooling, designed for dependable performance and modern GPU support. With best-in-class features, exceptional efficiency, and a silent 120mm be quiet! fan, it offers an outstanding balance of power, stability, and quiet operation.

Key Features

80 PLUS Gold efficiency up to 94.2% (at 230V, 50% load)
ATX 3.1 compliant PSU with full support for PCIe 5.1 GPUs and GPUs with 6+2 pin connectors
Handles massive power excursions for demanding systems
Exceptionally silent semi-passive 120mm be quiet! fan
Semi-passive operation for quiet, energy-saving performance
LLC technology for advanced stability and precise voltage regulation
Single high-performance 12V rail for reliable power delivery
1x PCIe 5.1 12V-2x6 450W connector and 2x PCIe 6+2-pin connectors for modern and overclocked high-end GPUs
Full suite of safety features for comprehensive protection
Meets latest modern standby requirements
10-year manufacturer’s warranty

Specifications

General Data

Parameter	Value
Model	Pure Power 13 M \| 650W
Continuous power (W)	650
Peak power (W)	720
Form factor	Version 3.1
Form factor EPS 12V	Version 2.92
Topology	LLC + SR + DC/DC
Digitally controlled	No
Voltage (Vac)	100 – 240
Frequency (Hz)	50 – 60
Input current (A)	10 / 5
Power factor at 100% load	>0.98
Modern standby	Yes
Power consumption in standby (W)	<0.1
Average lifetime (h / 25°C)	>100,000
Operating temperature up to (°C)	40

Efficiency

Parameter	Value
80 PLUS certification	Gold
Efficiency (%) at 230V, 2% load	71.1
Efficiency (%) at 230V, 10% load	90.0
Efficiency (%) at 230V, 20% load	93.1
Efficiency (%) at 230V, 50% load	94.2
Efficiency (%) at 230V, 100% load	92.8

Fan and Cooling

Parameter	Value
Cybenetics Noise Rating	No
Fan	Silence-optimized be quiet! fan
Fan size (mm)	120
Bearing technology	Rifle
Motor technology	4-pole fan motor
Max. fan speed (rpm)	1800
dB(A) at 10% load	n/a
dB(A) at 20% load	12.9
dB(A) at 50% load	13.2
dB(A) at 100% load	30.2

Output

Parameter	Value
Multi-rail operation (12V rails)	No
12V single rail operation	Yes
Overclocking key	No
+3.3V (A)	20
+5V (A)	20
+12V1 (A)	54.1
-12V (A)	0.3
+5Vsb (A)	3
Max. combined power 12V (W)	650
Max. combined power 12V-2x6 (W)	450
Max. combined power 3.3V + 5V (W)	120
Hold-up time at 100% load (ms)	22.5
Hold-up time at 80% load (ms)	30.66
Power good signal (ms)	100 – 150

Cables and Connectors

Parameter	Value
Modular cables	Yes
Sleeved cables	Yes
Flat cables	Yes
Maximum cable length (cm)	95
Cable length to motherboard (cm)	55
Number of cables	7
ATX-Motherboard (20+4-pin)	1
P4+4 (CPU)	1
P8 (CPU)	No
P4 (CPU)	1
12V-2x6 cables	1
PCI-E 6+2-pin (GPU)	2
PCI-E 6-pin (GPU)	No
SATA	5
PATA	2
FDD (Floppy)	No

Protection

Protection Type	Available
OTP (over temperature)	Yes
OCP (over current)	Yes
OPP (over power)	Yes
SCP (short circuit)	Yes
OVP (over voltage)	Yes
UVP (under voltage)	Yes
SIP (Surge & Inrush protection)	Yes

Safety Certification

Certification	Available
BSMI	Yes
CB	Yes
CCC	Yes
CE	Yes
cRUus	No
cTUVus	Yes
CU	Yes
FCC	Yes
RCM	Yes
TÜV	Yes
UKCA	Yes
IRAM	No

Environmental Directives

Directive	Compliant
ENERGY STAR	8.0
ErP	Yes
WEEE	Yes
RoHS	Yes
Triman	Yes

Scope of Delivery

Item	Included
Thumb screws	No
Screws	Yes
Cable ties	Yes
Velcro cable ties	No
User manual languages	CN, DE, EN, ES, FR, JP, PL, RU, TW
OCK slot bracket / OCK jumper	No
SFX-to-ATX adapter bracket	No
