Ubiquiti UDB Plug and Play Wireless Device Bridge
$170.00
Plug-and-Play Wireless Bridging PoE Adapter with UniFi WiFi Auto-Link
A compact, plug-and-play wireless bridging PoE adapter designed for simple deployment and integrated UniFi WiFi Auto-Link functionality.
Key Features
- Plug-and-play operation
- Wireless bridging PoE adapter
- Integrated UniFi WiFi Auto-Link
- Wall or table mounting options
- WiFi 5 with 2x2 MIMO and up to 866.7 Mbps (BW80)
- WPA2 AES wireless security (always on)
- Managed via WiFi
Technical Specifications
| Category | Details |
|---|---|
| Product Type | Wireless bridging PoE adapter with integrated UniFi WiFi Auto-Link |
| Dimensions | 130 x 55 x 34 mm (5.1 x 2.2 x 1.3") |
| Weight | 200 g (7.1 oz) |
| Mounting Locations | Wall / Table |
| Mount Material | Polycarbonate |
| Enclosure Material | Polycarbonate |
Wireless
| Category | Details |
|---|---|
| WiFi Standard | WiFi 5 |
| Spatial Streams | 2 |
| MIMO | 2 x 2 |
| Max. Data Rate | 866.7 Mbps (BW80) |
| Antennas | (1) Internal antenna (1) RP-SMA connector for external omni-antenna |
| Antenna Gain | Internal antenna: 5 dBi External omni antenna: 4 dB |
| Channel Bandwidth | 20/40/80 MHz |
| Wireless Security | WPA2 AES (Always On) |
Supported Data Rates
- 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n: 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
- 802.11ac (WiFi 5): 6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
Power
| Category | Details |
|---|---|
| Power Method | 100–240V AC, 0.45A Max., 50/60 Hz |
| Supported Voltage Range | 100–240V AC |
| Max. Power Consumption | 25W (AC input) / 10W (excluding PoE output) |
Interfaces & Management
| Category | Details |
|---|---|
| Networking Interface | (1) GbE RJ45 port |
| Management | WiFi |
| Button | (1) Factory-reset |
| System LEDs | (4) Blue: signal (1) White/blue: indicator |
Certifications
- CE
- FCC
- IC
